GYC01 Varnish Machine
  • GYC01 Varnish Machine
  • GYC01 Varnish Machine
  • GYC01 Varnish Machine
  • GYC01 Varnish Machine
GYC01 Varnish Machine GYC01 Varnish Machine GYC01 Varnish Machine GYC01 Varnish Machine

GYC01 Varnish Machine

    Basically this equipment is same as GYC01 base-coating machine.

Inquire Now
  • Application and operating principle
  • Main technical parameters
  • Main features

    Printed and dried cans require a hard layer over it to protect from any type of mechanical pressure. An epoxy or polyester is applied over it to form a hard and stable layer and also give glossy or matt finish.


    A. Can diameter range: φ35-φ53mm

    B. Can length range: ≤250mm

    C. Production speed: ≤120cans/min

    D. Motor power: 5.15KW

    E. Dimensions: 2750*2330*1760mm

    F. Net weight: 4500KG

    G. Intake pressure: ≥0.5Mpa


    A. It adopts SIEMENS PLC and Pro-face color touch screen to realize intelligent operations.

    B. Main units like mandrel plate and cam are processed by CNC equipment, which ensures operation and rotation accuracy of the mandrel.

    C. Manipulator takes cans up and down automatically. The machine has self-inspection system. If cans are not well inserted into mandrels, the machine will stop working. No cans, no printing. The mandrel can be automatically prevented from coating.

    D. Mandrel replacement aid system can make it easy to replace the mandrel.

    E. Most mandrels are FESTO pneumatic units, with NTN or NSK bearings.
